$1,679.00
| /
Premium monotube, height adjustable.
ORD Engineering suspension has been designed and developed with Pioneer engineering. This suspension has been rigorously tested offroad and on road here in Australia, through varying conditions including sand, snow, mud and towing heavy loads.
With its monotube design, and height adjustability, these kits are of the highest quality. These can be paired with various springs which will allow you tailor make your suspension kit. Polyutherane reduced bump stops (front) are included in our kits as standard.
The shocks contain an internal floating piston - this is one that floats between the high pressure Nitrogen Gas and the shock fluid keeping them separate to prevent cavitation and foaming. The IFP actively works as an internal air bump stop to help smooth out the harsh bumps and actively senses the terrain and adjusts according to the driving conditions giving you the ultimate in ride quality and control.
The shock absorbers contain comfort valving to ensure the ride of your vehicle is as smooth as possible.
Warranty - we stand behind our product, with a 4 year 80,00km warranty period on manufacturing defects. Warranty is registered online https://form.jotform.com/222441446451046
*Note - recommend upper control arms be replaced*
This kit is not sold with rear leaf springs. We can assist you to purchase these locally as the freight on these items is high. Once your purchase is confirmed we will contact you to discuss leaf spring options.
Specifications
- Monotube design - fully rebuildable
- Inverted monotube (shaft facing down) - optimum performance
- IFP -Internal floating piston for added comfort and control
- H/D 3mm Brushed steel nickel plated body - ultimate in strength and durability
- 52mm Outer body - increased fluid volume to prevent fade and improve control
- 20mm Hardened chrome heavy duty shaft
- Unique piston ring technology - full teflon band seal
- 46mm Piston Valve - Twin deflective disc for maximum control of fluid for both rebound and compression cycles
- Quality pure rubber bushes
- Multi-Stage velocity sensitive piston valve - Ultimate comfort and control
- NOK Seals, 5 levels of sealing
- Internal fluid - High quality shock absorber fluid able to withstand extreme temperatures
- Internal Shock Specifications - Micro polished internal tube bore
- Engineered for on road and offroad drivability and touring
- Adjustable spring seat (adjust the height of the lift)
- Premium spring options - linear and progressive options
- Long travel design - optimised for offroad
You will receive
- 2 x rear shock absorbers
- 2 x front springs
- 2 x front shock absorbers
- 2 x polyutherane reduced bump stops
